CONNECTORS & RECEPTACLES
QG ? PART NUMBERING SYSTEM PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
Q-G ? CONNECTOR PART NUMBERING
Number of
Series
Contacts
Gender
Options
A
CORD PLUG WITH SCREW CABLE CLAMP
3-7
M MALE
D
FAS-DISCONNECT (FEMALE CONNECTORS)
AA CORD PLUG WITH CRIMP CABLE CLAMP
F FEMALE
B
BLACK EPOXY FINISH
AAA CORD PLUG WITH TWIST ON HANDLE
B
C
D
FRONT PANEL MOUNT USING NUT
FRONT PANEL MOUNT - CIRCULAR
FRONT PANEL MOUNT - RECTANGULAR
FM BOTH
(S SERIES)
ST
RA
M
STRAIGHT PC TAILS
RIGHT ANGLE PC TAILS
MOMENTARY SWITCH ACTION
(T SERIES ONLY)
E
MODULAR FRONT PANEL MOUNT
PC PC TERMINALS (Y SERIES ONLY)
G WALL PLATE - 1 B SERIES MALE
H WALL PLATE - 2 B SERIES MALES
J WALL PLATE - 1 D SERIES FEMALE
K WALL PLATE - 2 D SERIES FEMALE
N
L
S
AU
KNURLED COUPLING NUT (L SERIES ONLY)
FLEX RELIEF FOR .250" TO .328" CABLE O.D.
SEE NOTE 1.
GOLD CONTACTS
L
MICROPHONE ADAPTER - INTERNAL THREAD
H
HOUSING ONLY
M
MICROPHONE ADAPTER - EXTERNAL THREAD
OPTIONS SHOWN IN ORDER OF APPEARANCE
N
P
QG
R
S
T
W
Y
CAP PLUG
GOOSENECK MOUNT
CONNECTOR INSERT
RIGHT-ANGLE CORD PLUG
MALE/FEMALE BARREL ADAPTER
CORD PLUG WITH ON-OFF SWITCH
RIGHT-ANGLE PANEL MOUNT
REAR PANEL MOUNT
Z
SCREWLESS STRAIN RELIEF
NOTE 1: S HAS DIFFERENT DESIGNATIONS DEPENDING ON THE SERIES.
FOR A, AA, AND T SERIES: SMALL FLEX RELIEF FOR .105" TO .205" CABLE OUTSIDE DIAMETER
FOR B, C, AND D SERIES: SANDED FRONT FACE FINISH
FOR G, H, J, AND K SERIES: STAINLESS STEEL WALL PLATE (STANDARD)
FOR N SERIES: SHORTING WIRING INSTALLED
NOTE 2: J, K AND T SERIES AVAILABLE IN FEMALE GENDER ONLY.
G, H, L, M, N, AND W SERIES AVAILABLE IN MALE GENDER ONLY.
PROFESSIONAL SERIES Q-G ? CONNECTOR PART NUMBERING SYSTEM
Number Of
Series
Contacts
Model
PROFESSIONAL SERIES
3
22
FEMALE CORD PLUGS
QGP
AQGP
PROFESSIONAL SERIES CORD PLUG
WITH CRIMP CABLE CLAMP
23
62
MALE CORD PLUGS
RECTANGULAR FEMALE PANEL MOUNT
63
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
RECTANGULAR MALE PANEL MOUNT
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
